Easy Band 25-200
The Easy Band 25-200 La is a simple to use bench banding machine particularly suitable for use in graphic arts, combining multiple products in promotional sales, perfumeries, fruit shops, etc. It is able to guarantee a banding speed of 25 cycles / min and uses 12 mm wide ribbons. Its maximum banding span is W 220 x H 170 mm.
Technical specifications
|
Machine dimension |
382 Length, 280 Width, 413 Height (mm) |
|
Weight |
18 Kg |
|
Power supply |
220 V |
|
Power supply frequency |
50/60 Hz |
|
Production capacity |
25 cycles |
|
Coil holder |
Integrated |
|
Band type |
OPP Film |
|
Band width |
12 mm |
|
Banding tension |
5 - 40 N |
|
Closing system |
Thermal welding |
|
Reel internal diameter |
40 mm |
|
Coil outer diameter |
160 mm |
|
Dimension min. product |
30 Width, 10 Height (mm) |
|
Max. product size |
220 Width, 170 Height (mm) |
 Easy Band 25-200 |
